ALSYNITE ULTRA adalah lembaran Fibre Reinforced Polyester (FRP) yang tahan terhadap cuaca untuk waktu yang lama.
Fitur baru yang ditambahkan adalah ultra violet surface protection film. Digabung dengan formula unik polyester resin, Dengan dukungan sistem tercanggih dengan bangga kami memberikan garansi selama 25 tahun.
Tersedia berbagai pilihan profil, berat dan warna, Alsynite Ultra adalah pilihan terbaik untuk solusi aplikasi atap dan dinding bangunan
Key Features
- Tahan terhadap perubahan cuaca dalam waktu yang sangat lama
- Garansi selama 25 tahun *syarat dan kondisi berlaku
- Non delaminating surface technology
- Teknologi anti retak dan pemudaran warna
- Sangat tahan terhadap erosi
- Tahan terhadap senyawa kimiawi tertentu
- Kejernihan yang awet dalam waktu yang lama
Tipe Aplikasi
- Atap kaca untuk komersil dan industri
- Jendela kaca gedung
- Kamar anak kecil & area eceran
- Beranda parkiran mobil & pelindung pergola
- Fentilasi
Color and Solar Optical Properties
Properties
|
Clear
|
Opal
|
Thermal conductivity (%)
|
72
|
62
|
UV Resistance (%)
|
99.9
|
100
|
Diffused Light Transmission (%)
|
74
|
55
|
Solar Heat gain (W/m2)
|
560
|
486
|
Transmittance 380 - 320nm (UV-A)
|
0.04
|
-
|
Transmittance 320 - 280nm (UV-B)
|
0.006
|
-
|
*The above data is based on a 2400GSM, 1.5mm sheet. Customized colors are available, subject to minimum order quantities and pigment availability. The combination of color and weight will affect the amount of light transmitted through the sheet.
Product Specifications
Profiles
|
Due to Alsynite's global presence, we have an extensive range of profiles within our portfolio that matches most metal sheeting profiles.
|
|---|---|
Sheet Length
|
Standard sheet lengths up to 11.9 meters. Other non-standard lengths are available subject to special order and shipping parameters.
|
Weights
|
The standard weight for industrial applications is 2400 gsm. For sheet weights not listed, please contact your nearest Alsynite distributor for further details.
|
Nominal Thickness
|
1.2mm, 1.5mm, 2.0mm ± 15%
|
Surface Coating
|
World renowned improved UV protection film. 20 micron nominal thickness.
|
Colors
|
Standard colors of Clear and Opal.
Customized colors are available, subject to minimum order quantities and pigment availability.
The combination of color and weight will affect the amount of light transmitted through the sheet.
|
Resin System
|
Advanced general purpose grade orthophthalic polyester.
|
Reinforcement
|
"E" Class Fibre optic glass, at least 22%
|
Light Transmission
|
Clear 74%, Opal 58% (Using 2400 gsm 1.5mm sheet)
|
Thermal Conductivity
|
Clear 72%, Opal 62% (Using 2400 gsm 1.5mm sheet)
|
Heat Distortion Temperature
|
+180 to 200
|
Thermal Expansion
|
2.5 x 10-5 cm/cm/C
|
UV Resistance
|
Clear 99.9%, Opal 100%
|
Mechanical Properties
PROPERTIES
|
Tensile Strength
|
Shear Strength
|
|---|---|---|
TEST VALUE
|
94MPa
|
90MPa
|
PROPERTIES
|
Compressive Strength
|
Barcol Hardness
|
TEST VALUE
|
135MPa
|
> 50
|
Physical Properties
PROPERTIES
|
Thermal Expansion
(10-5cm/cm/°C) |
Water Absorption
(%) |
|---|---|---|
TEST VALUE
|
2.2
|
0.52 to 0.60
|
PROPERTIES
|
Heat Distortion Temperature (°C)
|
Operating Temperatures (°C)
|
TEST VALUE
|
+180 to 200
|
-20 to +95
|
Solar Optical Properties
PROPERTIES
|
Diffused Light Transmission (%)
|
Solar Heat Gain (W/m2
|
|---|---|---|
CLEAR
|
74
|
560
|
OPAL
|
58
|
486
|
PROPERTIES
|
Transmittance 380-320nm (UV – A)
|
Transmittance 320-280nm (UV – B)
|
CLEAR
|
0.04
|
0.006
|
OPAL
|
-
|
-
|
Results of tests are based on a 2400 gsm sheet.
 |
 |
|
|
